Ready to use Active LED Panel with Superior Quality
Creativity with simplicity, SAIPUR is a dedicated category brand specially established by SAIPUR for the global LED display channel market based on the development concept of “Ready-to-use LED, to fityour demands”. SAIPUR Active LED Indoor have excellent performance, simple design, flexible splicing, convenient maimtenance and other characteristics.
Features
- Ready-to-use panel
- Vivid performance
- Flexible splicing
- Quick installation & service
| Parameter | P1.9 | Parameter | P1.9 |
|---|---|---|---|
| Panel Dimensions (W*H, mm) | 320×480×55 | Panel Resolution | 172x258 |
| Pixel Weight (kg) | 2.5 | Module Size (W*H, mm) | 320×160 |
| Brightness (nit) | 500 | Refresh Rate (Hz) | 3840 |
| Grayscale (bit) | 14 | Viewing Angle (H/V, °) | 160/140 |
| Storage Temperature (℃) | ﹣40~﹢60 | Power Consumption (max./avg. W/m²) | 320/107 |
| Operating Temperature (℃) | ﹣10~﹢40 | Storage Humidity (RH) | 10﹪~85﹪ |
| Operating Humidity (RH) | 10﹪~80﹪ | IP Rating | IP40/IP21 |
| Certificate | CCC, FCC, ETL, CE, RoHS |
